Built for Seamless, High-Quality Welds
Rutile-type gas shielded flux cored wire
Designed for optimum performance with 100% CO₂ shielding gas
Low fumes and minimal spatter for cleaner work environments
All-position welding capability for versatile applications
Easy slag removal with weld metal free of inclusions and porosity
Radiographic quality welds for superior structural integrity
Versatile Solutions Across Heavy-Duty Industries
Welding C-Mn steel with tensile strength up to 550 N/mm²
Chemical plant machinery, ship hulls, and structural steel fabrication
Bridges, towers, cranes, and shipbuilding
Construction equipment, farm machinery, and rolling stock
Joining steels conforming to ASTM SA 36/36M; Grade A/B/C/D of SA 283/283M and SA 414/414M
Packaging Data
Vacuum Pack: 15 kg wire layer wound on plastic spool
Drum Packing: Available in 100 kg and 250 kg options
Welding Parameters
| Diameter (mm) | Flat & Horizontal (Current/Volt) | Vertical Up (Current/Volt) | Overhead (Current/Volt) |
| 1.20 | 150 - 250 A / 24 - 30 V | 100 - 200 A / 20 - 26 V | 120 - 200 A / 22 - 30 V |
| 1.60 | 180 - 300 A / 24 - 32 V | 120 - 220 A / 20 - 26 V | 150 - 250 A / 22 - 32 V |
Shielding Gas: 100% CO₂, Flow rate 15-25 LPM
Chemical Composition of Weld Metal (%):
| Element | Component | Specification |
| Carbon (C) | 0.06 | 0.12 |
| Manganese (Mn) | 1.20 | 1.75 |
| Silicon (Si) | 0.40 | 0.90 |
| Sulfur (S) | 0.010 | 0.030 |
| Phosphorus (P) | 0.015 | 0.030 |
| Chromium (Cr) | 0.020 | 0.20 |
| Nickel (Ni) | 0.015 | 0.50 |
| Molybdenum (Mo) | 0.010 | 0.30 |
| Vanadium (V) | 0.010 | 0.08 |
| Copper (Cu) | 0.010 | 0.35 |
Mechanical Properties of Weld Metal
| Condition | UTS (N/mm²) | YS (N/mm²) | Elongation (%) | CVN Impact at -20°C (J) |
| Typical (As welded) | 550 | 460 | 27 | 60 |
| Specification | 490 - 670 | 390 Min | 22 Min | 27 Min |
Welding Positions: F, H, V-UP, OH.
