MANGALAM^®
M.S. Electrodes- E6013

Versatile Performance for Precision Welding

The M.S. Electrodes - E6013 is a medium-coated, all-position rutile type electrode designed for light to medium structural applications. With exceptional mechanical and radiographic qualities, it ensures high-quality welds with minimal spatter and smoke. The easy-to-remove slag and consistent performance make it ideal for a wide range of applications, including pipes and tubes up to 12 mm in thickness.

Quantity :

SWG Size 6 SWG Size 8 SWG Size 10 SWG Size 12

Buy Now Download Brochure

Features

Innovative Design, Unmatched Efficiency

Reliable, high-quality weld deposits.
Easy slag removal for a seamless finish.
Minimal spatter and smoke for cleaner operations.
Suitable for all welding positions (Flat, Horizontal, Vertical-Up, Vertical-Down, Overhead).

Engineered for Diverse Industrial Needs

Railway coaches, locomotive fireboxes, and wagons.
General fabrication of vessels, storage tanks, and boilers.
Construction projects such as bridges and structural frameworks.
Automobile frames and bodies.
Shipbuilding and pipelines.
Furniture manufacturing.

Packing Data

SWG Size	Size (mm)	Electrodes/Packet	Electrodes/Carton	Current (Amps)
12	2.50 x 350	125	1500	80 - 110
10	3.15 x 350	90	1080	90 - 130
8	4.00 x 350/450	60	720	140 - 190
6	5.00 x 450	40	480	170 - 230
