Advanced Design, Reliable Results
High deoxidizer content for weld integrity in adverse conditions.
Uniform copper coating for consistent, smooth wire feeding.
Stable arc with reduced spatter for cleaner welds.
Optimized for high-speed robotic, automatic, and semi-automatic welding.
Supports multiple welding positions (Flat, Horizontal, Vertical-Up, Vertical-Down, Overhead).
Versatile Solutions for Heavy-Duty Industries
Construction and mining equipment
Pressure vessels, pipelines, and ductwork
LPG cylinders and thin-sheet auto body work
Shipping containers, railway wagons, and coaches
High-speed robotic and semi-automatic welding
Packing Data
| Size (mm) | KG / Spool | Voltage (V) | Current (Amps) |
| 0.80 | 15 | 17 - 24 | 70 - 220 |
| 1.00 | 15 | 20 - 28 | 100 - 275 |
| 1.20 | 15 | 24 - 30 | 150 - 300 |
| 1.60 | 15 | 24 - 36 | 150 - 450 |
Shielding Gas: CO₂ / 80Ar + 20CO₂ / Ar (100%)
Flow Rate: 10 – 25 LPM
Chemical Composition of Weld Metal (%)
Mechanical Properties of All Weld Metal
| Element | Composition (%) |
| Carbon (C) | 0.06 - 0.15 |
| Manganese (Mn) | 1.40 - 1.85 |
| Silicon (Si) | 0.80 - 1.15 |
| Sulfur (S) | 0.035 Max |
| Phosphorus (P) | 0.025 Max |
| Copper (Cu) | 0.50 Max |
| Property | Value |
| UTS | 490 N/mm² Min |
| YS | 400 N/mm² Min |
| Elongation | 22% Min |
| CVN Impact at -30°C | 27 J Min |
Current Conditions
Operates on DC current.
Welding Positions: F, H, V-UP, V-DOWN, OH.
